SM2H21 Safety modules

Price 15200 INR/ Piece

Get a Price/Quote

MOQ : 1 Unit

SM2H21 Safety modules Specification

Locking Type
Screw clamp terminals

Weight
Approx. 160 g

Usage & Applications
Safety relay logic, Emergency stopping, Guard monitoring

Core Number
2

Conductor Shape
Round (internal wiring)

Rated Temperature
-25C to +55C

Install Type
DIN Rail Mount

Operating Temperature
-25C to +55C

Conductor Type
Stranded (internal wiring)

Features
Fail-safe design, Compact Size, LED Status Indicators, Fixed Configuration, Multiple Safety Functions, Fast Response Time

Number of Conductor
2 or more, depending on application

Core Material
Copper

Dielectiric Strength
2.5 kV AC 50 Hz, 1 min

Insulation
Double insulation

Product Type
Safety Module

Length
45 mm

Voltage
24V DC

Insulation Material
Heat-resistant Plastic

Application
Industrial Safety Control Systems, Emergency Stop Circuits, Machine Safety Interlocks

Conductor Material
Copper (internal circuitry)

Storage Temperature
-40C to +70C

Connector Color
Yellow

Dimension (L*W*H)
101 mm x 22.5 mm x 120 mm

Color
Yellow

Material
High-Durability Plastic, Metal Terminals

Size
22.5 mm housing width

Maximum Switching Current
6A at 250V AC

Relative Humidity
10% to 95% (non-condensing)

Electrical Life
100,000 operations at rated load

Environmental Compliance
RoHS compliant

Mounting Method
35 mm DIN Rail

Power Consumption
1.5 W max

Output Type
2 NO safety outputs, 1 NC feedback/contact

Standards
EN 60947-5-1, EN 60204-1

Response Time
< 20 ms

Control Voltage
24V DC

Degree of Protection
IP20

Cross-section of Connectable Wires
0.25 to 2.5 mm2

Mechanical Life
10,000,000 operations

Indication
LED power and channel status indicators

Input Channel
2 channels

About SM2H21 Safety modules

Introducing the distinguished SM2H21 Safety Module, a notable new release with competitive pricing and exclusive discounts for bulk buyers. This pivotal industrial safety device is engineered with dual input channels, two NO safety outputs, and robust 1 NC feedback architecture for comprehensive monitoring. Built from high-durability, heat-resistant plastic and featuring double insulation as well as RoHS compliance, it ensures reliable performance in the harshest environments. Fast response times (<20 ms), compact design, and LED indicators make it ideal for emergency stop circuits, machine safety interlocks, and safety relay logic, adhering to EN and IEC standards for assured safety.

Versatility and Material Excellence for Demanding Safety Applications

The SM2H21 Safety Module is ideally suited for industrial safety control systems and emergency stop circuits. Crafted from high-durability, heat-resistant plastic, the module delivers remarkable longevity even under challenging operational conditions. Designed for DIN Rail mounting, it supports easy installation using screw clamp terminals. Its application method enables swift incorporation into new and existing machine safety interlocks, delivering fail-safe operation and multi-functionality in a compact yellow housing.

Rapid Arrival, Robust Supply and Competitive Lowest Price Assurance

With a strong supply ability, SM2H21 Safety Modules are ready for immediate dispatching to your location. Samples are available, allowing comprehensive evaluation before placing bulk orders. Serving the main domestic market in Italy, these safety modules arrive quickly and are offered at the lowest price without compromising quality. Reliable delivery guarantees prompt installation for clients, procuring both distinguished safety and noteworthy cost efficiency.

FAQs of SM2H21 Safety modules:

Q: How is the SM2H21 Safety Module installed in an industrial safety system?

A: The module features a 35 mm DIN Rail mounting method, allowing for straightforward and secure installation into control panels using screw clamp terminals.

Q: What applications are suitable for the SM2H21 Safety Module?

A: It is suitable for safety relay logic, emergency stopping, guard monitoring, and machine safety interlocks, especially in industrial safety control environments.

Q: When is sample availability offered for the SM2H21 Safety Module?

A: Samples of the SM2H21 are available upon request, ensuring customers can evaluate performance and compatibility before bulk purchasing.

Q: Where can the SM2H21 Safety Module be sourced or dispatched from?

A: The SM2H21 is supplied by manufacturers, exporters, and suppliers in Italy and can be quickly dispatched throughout the main domestic market.

Q: What are the key benefits of using the SM2H21 Safety Module?

A: Benefits include a fail-safe design, fast response times, mechanical life exceeding 10 million operations, RoHS compliance, and clear LED status indicators for reliable system monitoring.

Q: How does the SM2H21 Safety Module ensure safety compliance?

A: It is certified according to EN 60947-5-1 and EN 60204-1 standards and features double insulation with a dielectric strength of 2.5 kV for electrical safety.
